Transcatheter Aortic Valve Replacement in a Patient With Levo-Transposition of the Great ArteriesOpen Access

History of Presentation

A 63-year-old White man with history of levo-transposition of the great arteries (LTGA) presented with progressive fatigue and shortness of breath for the last several months. He denied lower extremity edema, palpitations, dizziness, lightheadedness, or syncope. His vitals included heart rate of 90 beats/min, blood pressure of 114/63 mm Hg, and respiratory rate of 16 breaths/min. On examination, he had a grade III/VI systolic ejection murmur over the upper sternal border and a grade II/VI pansystolic murmur over the left lower sternal border.

Past Medical History

The patient was diagnosed with LTGA during childhood and followed with a cardiologist. He did not have any other cardiac anomalies associated with LTGA, such as ventricular septal defect, pulmonic stenosis, or tricuspid valve dysplasia (1,2). His only surgical history was dual-chamber pacemaker placement for complete heart block 10 years ago. He was on rivaroxaban for paroxysmal atrial fibrillation. The patient had a history of rheumatic fever as a child but no records were available for review. A transthoracic echocardiogram (TTE) done 2 years prior showed normal biventricular function, aortic sclerosis, and mild aortic stenosis. Other noncardiac history included obstructive sleep apnea on continuous positive airway pressure, type II diabetes mellitus, and hyperlipidemia.

Differential Diagnosis

LTGA is characterized by an acyanotic functional reversal of the right and left ventricles in the sequence of blood flow so that systemic venous “blue” blood via right atrium and left atrioventricular (mitral) valve reaches the right-sided morphologic left ventricle, which is connected to the pulmonary artery; the pulmonary venous “red” blood via the right atrioventricular (tricuspid) valve reaches the left-sided morphologic right ventricle, which is connected to the anteriorly placed aorta. The differential diagnosis for dyspnea on exertion and fatigue in an adult patient with LTGA includes:

Investigations

Electrocardiogram showed atrial-sensed ventricular-paced rhythm unchanged from prior. TTE (Videos 1A and 1D) showed moderately reduced systemic ventricular function (right ventricular ejection fraction, 35% to 40%) and subpulmonic ventricular function (left ventricular ejection fraction, 40%). There was mild tricuspid regurgitation (Video 1B). The aortic valve was thickened and calcified with reduced mobility (Videos 1C and 2A). Two-dimensional and Doppler findings were consistent with low-flow low-gradient aortic stenosis (Figure 1, Video 1E). The peak gradient was 33 mm Hg with a mean gradient of 19 mm Hg. Coronary angiogram demonstrated mild nonobstructive coronary artery disease.

Based on the elevated Doppler gradient and aortic valve appearance on TTE we suspected that his aortic valve stenosis could be clinically and hemodynamically significant. Therefore, we elected to perform a hemodynamic catheterization at rest and with dobutamine to evaluate for low-flow low-gradient aortic stenosis.

Hemodynamic catheterization demonstrated an aortic valve gradient of 28 mm Hg, Fick cardiac output of 4.2 l/min, and aortic valve area of 0.9 cm² per the Hakki equation (7). With dobutamine 20 μg/kg/min, the aortic valve gradient increased to 39 mm Hg, cardiac output increased to 4.8 l/min, and aortic valve area remained 0.9 cm². This demonstrated that with increasing cardiac output the aortic valve gradient increased 2-fold, whereas the aortic valve area remained in the severe range, confirming the diagnosis of low-flow low-gradient aortic stenosis.

Management

The patient was assessed in our adult congenital heart disease and interventional cardiology clinics. Based on the presence of symptomatic severe low-flow low-gradient aortic stenosis, we recommended aortic valve replacement and referred to cardiothoracic surgery. He was deemed a high surgical risk because of severe biventricular dysfunction. After discussion in the multidisciplinary case conference, plans were made for transcatheter aortic valve replacement (TAVR). Computed tomography angiography for TAVR evaluation was performed, which showed calcific valvular aortic stenosis with restricted leaflet mobility (Video 2B).

With pre-procedural planning with computed tomography and transesophageal echocardiology guidance intraprocedurally, the patient underwent placement of Medtronic 34 CoreValve Evolute R (Minneapolis, Minnesota) via right iliofemoral approach and tolerated the procedure with no complications.

Discussion

There are several characteristics that make this case unique. First, aortic stenosis in LTGA is rare and has not been reported in the absence of bicuspid aortic valve (5). We suspect this aortic stenosis may have been caused by the patient’s history of rheumatic fever as a child. Patients with LTGA typically develop failure of the systemic tricuspid valve and systemic ventricular dysfunction (3).

Diagnosis was also challenging because of poor echocardiographic windows and complex anatomy. Moreover, because the LTGA aortic valve is in the right ventricular outflow tract (RVOT) instead of the left ventricular outflow tract (LVOT), we could not calculate aortic valve area using the continuity equation because it relies on geometric assumptions for the LVOT but not the RVOT (8). The RVOT is comparatively more muscular, more variable, and more contractile than the LVOT. In addition, it is difficult to obtain an accurate RVOT diameter on TTE.

TAVR placement in the RVOT is also uniquely difficult. The RVOT has a much larger area and more significant variance throughout systole and diastole than the LVOT. Because of the close proximity of the aortic valve and tricuspid valve, tricuspid regurgitation is a concern. Furthermore, the levorotation of the heart and anteriorly placed aorta makes catheter manipulation atypical, with the levo-transposition yielding a high risk of atrioventricular block. Finally, LTGA is frequently associated with coronary anomalies, so the valve placement must consider altered coronary anatomy as well.

Despite the challenges of placing a transcatheter aortic valve in the RVOT, with careful pre-procedural planning our outcome was excellent. In our literature search we could find only 1 report of TAVR placement in the RVOT of an LTGA patient, although in that case the patient did not survive to 1-year post-operation (9).

Follow-Up

As of most recent follow-up 12 months post-operative, the patient has done well with improved functional capacity back to baseline. Follow-up TTE was performed, which showed improved systemic right ventricle ejection fraction of 55% and estimated mean gradient of 8 mm Hg, with only trivial tricuspid valve regurgitation.

Conclusions

TAVR was successful in our patient with LTGA with improvement in symptoms, functional capacity, and echocardiographic measures of systemic and subpulmonic ventricular function without worsening of systemic tricuspid valve function. TAVR can be used as a strategy in LTGA patients who are at high risk of surgery.
